Used 2017 Mercury 250 HP Pro XS OptiMax 2-Stroke Outboard Motor – 20" Shaft – 151 Hours – 110–115 PSI Compression – Torque Master II

PRODUCT DESCRIPTION

This 2017 Mercury 250 HP Pro XS OptiMax is a high-performance 2-stroke outboard with only 151 hours and strong, even compression readings of 110–115 PSI across all six cylinders.

The engine is equipped with the performance-oriented Torque Master II lower unit, which has been pressure tested to 13 PSI and held pressure. Idle air pressure is reported at 99 PSI.

This 250 Pro XS features Mercury's proven 3.0-liter V6 direct-fuel-injection (DFI) 2-stroke platform, producing 250 HP with strong acceleration and performance for bass, tournament, offshore, and other high-performance applications. Mercury's 2017 specifications list the 250 Pro XS/OptiMax platform as a 3.0L V6 with a 1.75:1 gear ratio and 20" or 25" shaft configurations.

With only 151 hours and excellent cylinder-to-cylinder compression consistency, this is an attractive option for a performance-oriented repower.

TECHNICAL SPECIFICATIONS

• Brand: Mercury
• Model: 250 Pro XS
• Model Designation: 250 PXST2
• Year: 2017
• Horsepower: 250 HP
• Engine Type: 2-Stroke Direct Fuel Injection (DFI)
• Configuration: 60° V6
• Displacement: 3.0L / 3,032cc
• Shaft Length: 20"
• Engine Hours: 151
• Compression: 110–115 PSI across all cylinders
• Starting: Electric Start
• Steering: Remote
• Trim & Tilt: Power Trim & Tilt
• Gear Ratio: 1.75:1
• Lower Unit: Torque Master II
• Lower Unit Pressure Test: Held at 13 PSI
• Idle Air Pressure: 99 PSI
• Dry Weight: Approximately 505 lbs
• Condition: Used
• Rotation: Standard — Verify

FEATURES

• 250 HP Pro XS performance
• 3.0L V6 2-stroke DFI
• Only 151 hours
• 110–115 PSI compression across all cylinders
• Excellent compression consistency
• 20" shaft
• Torque Master II lower unit
• Lower unit pressure tested to 13 PSI and held
• 99 PSI reported idle air pressure
• Electric start
• Power trim and tilt
• Remote steering
• SmartCraft-compatible platform
• High-performance Pro XS configuration

WHY YOU'LL LOVE IT

The Mercury 250 Pro XS was designed for boaters who want serious performance without moving to a modern four-stroke platform. The 3.0L V6 OptiMax/DFI architecture provides strong acceleration and performance, while the Pro XS configuration and Torque Master gearcase are particularly well suited to performance and tournament applications.

At only 151 hours, with compression readings of 110–115 PSI across all cylinders, this engine offers an especially attractive combination of relatively low hours and even cylinder readings.

PERFORMANCE & APPLICATIONS

The 250 Pro XS is designed for high-performance applications where acceleration, top-end performance, and strong power delivery are priorities.

Ideal applications can include:

• Bass boats
• Tournament fishing boats
• Performance fishing boats
• Multi-species fishing boats
• Larger center-console boats rated for 250 HP
• High-performance repower projects

Always confirm your boat's maximum horsepower rating, shaft length, weight capacity, steering system, and rigging compatibility before installation.

COMPATIBLE BOAT TYPES

This 250 HP Pro XS may be suitable for:

• Bass boats
• Performance fishing boats
• Center-console boats
• Multi-species fishing boats
• Fiberglass fishing boats
• Other boats rated for a 250 HP outboard

CONDITION

Used

• 151 hours
• 110–115 PSI compression across all cylinders
• Torque Master II lower unit
• Lower unit pressure tested and held 13 PSI
• 99 PSI reported idle air pressure
• Performance-oriented Pro XS configuration

WHAT'S INCLUDED

• Mercury 250 HP Pro XS outboard
• 20" shaft
• Torque Master II lower unit
• Electric-start system
• Power trim and tilt
• Remote steering system
• Complete package required to mount and operate the motor

Controls and rigging are available — please confirm the exact components included with the motor before ordering.

WARRANTY

1-Year Warranty

This used outboard is backed by a 1-year EZ Boats Marine warranty.

SHIPPING INFORMATION

We offer flat-rate shipping of $350 per motor throughout the continental United States.

IMPORTANT DELIVERY INFORMATION

Please inspect the package carefully upon delivery and document any visible shipping damage before accepting the shipment.

Before ordering, confirm:

• 20" shaft requirement
• Boat's maximum horsepower rating
• Engine weight capacity
• Steering compatibility
• Control and rigging compatibility
• Propeller requirements
• SmartCraft requirements
• Required gauges and harnesses

WHY BUY FROM EZ BOATS MARINE?

• Quality used outboard motors
• Complete ready-to-run packages
• 1-year warranty on used motors
• Flat-rate continental U.S. shipping
• Competitive repower options
• Support throughout the purchasing and installation process

FREQUENTLY ASKED QUESTIONS

How many hours are on this Mercury 250 Pro XS? The motor has 151 hours.

What shaft length does it have? It has a 20-inch shaft.

What type of engine is it? It is a 3.0L V6 2-stroke direct-fuel-injection (DFI) Mercury Pro XS/OptiMax platform. Mercury's period specifications identify the 250 Pro XS as a 3.0L V6 2-stroke DFI engine.

What are the compression readings? Compression is reported at 110–115 PSI across all cylinders, providing a very even cylinder-to-cylinder result.

What lower unit does it have? It is equipped with a Torque Master II lower unit.

Has the lower unit been pressure tested? Yes. The supplied test information states that it was pressure tested to 13 PSI and held.

What is the idle air pressure? The supplied test information reports 99 PSI idle air pressure.

Does it have power trim and tilt? Yes.

Are controls and rigging included? The supplier indicates that controls and rigging details are available. The exact components included should be confirmed before purchase.
